Data transfer between the module and the Quantum processor is asynchronous to the DF1 network, with the module's internal database being used to exchange data between the Quantum processor and the DF1 network. The module has two serial ports supporting the DF1 protocol, with each port user configurable to act as a Master or as a Slave.
Acyclic parameter data can be transferred with Class 1 or Class 2 DP-V1 services, allowing processors to easily communicate with slave devices supporting PROFIBUS DP-V0 or DP-V1 protocol.
The PROFIBUS DP Master Network Interface Module for Quantum is designed according to IEC 61158 specifications and has been tested and certified according to PTO guidelines to guarantee proper interoperability on a PROFIBUS network. Developed under license from Schneider Electric, the module incorporates proprietary backplane technology that enables powerful data exchange with Quantum processors. The PROFIBUS DP Master Network Interface Module for Quantum is a powerful communication interface for Quantum platform processors. PROFIBUS DPV1 Master Module for Unity/Quantum CPUs - PTQ-PDPMV1
